PIONEER SPEC-2 Vintage 500-watt Stereo Power Amp AUTHORIZED-DEALER - $1,400 - (Green Bay, WI)

PREOWNED - FULLY TESTEDThe Spec-2 is a 250W rack mount stereo power amplifier featuring a current limiter circuit, peak level meters, protection circuit, power switch on/off and impedance selector muting and a temperature detector.This high power design employs a cascaded differential amplifier first stage, push-pull drive, and darlington triple push-pull circuit with all stages direct coupled (OCL).SpecificationsPower output: 250 watts per channel into 8? (stereo)Frequency response: 5Hz to 80kHzTotal harmonic distortion: 0.1%Damping factor: 50Input sensitivity: 2VSignal to noise ratio: 110dBSpeaker load impedance: 4? to 8?Semiconductors: 55 x transistors, 75 x diodesDimensions: 480 x 186.5 x 445mm Weight: 24.3kg
