RigExpert AA-520 powerful antenna analyzer 1 to 520 MHz range - $485 - (Jamestown, OH)

RigExpert AA-520 Antenna Analyzer 1 to 520 MHz RigExpert AA-520 is a powerful antenna analyzer designed for testing, checking, tuning or repairing antennas and antenna feedlines in 1 to 520 MHz range. Mainly, this is SWR (Standing Wave Ratio) and impedance measurement instrument (impedance analyzer). Easy-to use measurement modes, as well as additional features such as memory storage and connection to a personal computer, make the AA-520 attractive for professionals and hobbyists. It is quite important that graphical display of various parameters over a wide frequency range is a key feature of this analyzer which significantly reduces the time required to adjust an antenna. The new MultiSWR™ mode is unique for this antenna analyzer. The following tasks are easily accomplished by using RigExpert AA-520: Rapid check-out of an antenna Tuning an antenna to resonance Antenna SWR and impedance measurement and comparison before and after specific event (rain, hurricane, etc.) Making coaxial lines or measuring their parameters Cable fault location Measuring capacitance or inductance of reactive loads Antenna analyzer comparison table See also: A short review of antenna and network analyzers Download the RigExpert AA-520 User's manual Download the RigExpert AA-520 Software manual RigExpert is a registered trademark of Rig Expert Ukraine Ltd. RigExpert AA-520 Specifications Frequency range: 1…520 MHz Display modes: - SWR at single frequency - SWR, R, |X|, Z, L, C at single frequency - SWR graph - R, |X| graph Single- and multi-frequency measurement: - Frequency resolution: 1 kHz - SWR only mode: easily-readable bar - SWR range: 1…10 - SWR display for 50 Ohm systems - R, |X| range: 0…250 Ohm SWR and R, X graphs: - 100 points plot - Sweep width: 1…520 MHz - Frequency resolution: 1 kHz - SWR range: 1…10 - SWR display for 50 Ohm systems - R, |X| range: 0…200 Ohm - 100 memories to store and recall graphs - Presets for radio amateur bands RF output: - Connector typ…

Posted in Jamestown, OH, Electronics
From ebay.com - 1 month ago
