Mazak VTC-41 CNC Vertical Milling Machine Machining Center - $8,000 - (Lakewood, WA)

Manufacturer & Model: MAZAK Model VTC-41 X- Axis, Column Travel L-R: 22.04" Y- Axis Col. Travel In-Out: 16.14" Z-Axis Head Travel Up-Down: 20.07" Dist. Table to Spindle Nose: 4.3" - 24.4" Dist. Column front to Spindle Ctr: 18.1" Table Size: 35.5" x 16.1"Table Load Capacity: 660 lbsSpindle Speeds: 40 - 7000 RPM Ranges: Continuously Variable Spindle Taper: #40 Rapid traverse: X & Y 787 in. / min Auto Tool Changer Capacity: 24 Tool selection method: Random shortest path Tool change cycle: 8 sec. (chip to chip) Spindle Motor (5 min, 30 min, cont): AC 11 kW (15HP), 7½ kW(10HP) 5.5 kW(7.5HP) Tank Cap: 37 gal DIMENSIONSMETRICSTANDARDHeight2630 mm103.5"Floor Space2265 mm (88.8") x 2690 mm105.9"Machine weight 8000 lbs.Mazatrol EIA/MB Control Specifications: This machine will need the spindle bearings replaced. Everything else works as it should for a 26 year old machine. This machine is equipped with a step down transformer and can be used for 240v or 480v. The rear sliding cover is missing and replaced with a rubber sheet. Comes with manuals. The machine is powered down and prepped for shipment. Please feel free to ask any questions.

Posted in Lakewood, WA, Business for Sale
From ebay.com - 1 month ago
