Mazak cnc Lathe QTN300M - $74,500 - (Bridgeview, IL)
2004 MAZAK QTN-300M SPECIFICATIONS: MAXIMUM SWING.................. 29.5" MAX CUTTING DIAMETER........... 16.5" MAX CUTTING LENGTH............. 46.2" CENTER DISTANCE…………… 48” BAR CAPACITY................... 3" SPINDLE BORE................... 3.46" SPINDLE NOSE................... A2-8 SPINDLE MOTOR.................. 35/30 HP SPINDLE SPEED.................. 4,000 RPM X-AXIS TRAVEL.................. 10.13" Z-AXIS TRAVEL.................. 48.75" RAPID TRAVERSE RATE (X)........ 1181 IPM RAPID TRAVERSE RATE (Z)........ 984 IPM LIVE TOOLING MOTOR............. 10 HP LIVE TOOLING SPEED............. 4,000 RPM TURRET CAPACITY................ 12-STATION EQUIPPED WITH: MAZATROL 640T NEXUS CONTROL LIVE MILLING 10”, 3-JAW SMW HYDRAULIC CHUCK TAILSTOCK TOOL PRESETTER PARTS CATCHER CHIP CONVEYOR (JORGENSEN) HIGH-PRESSURE COOLANT (118 PSI) MIST COLLECTOR & STAND MILLING SPINDLE SYNCHRONOUS TAPPING (6) AXIAL LIVE TOOL HOLDERS (1) RADIAL LIVE TOOL HOLDER BOX WAY ** AS OF 12/2018, TOTAL CUT TIME – 7,466 HOURS ** MACHINE CUT PRIMARILY CARBON STEEL, ALUMINUM & BRASS ** IN PLANT, UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
