Sirio Professional Omni SPO 420-5 5 dBi UHF Base Antenna (420-470mhz) - $165 - (Fremont, CA)

New series of wide band omnidirectional base station antennas for UHF band suitable for marine service too. The fiberglass protection radome and the anodized aluminium parts guarantee robustness and long life to all the SPO-antennas series. They are supplied with two strong extruded aluminium brackets and stainless steel hardware for a good installation on the mast. Features: Base station antenna, Wide-band Medium-gain, Omnidirectional Suitable for land and marine service Protection from static discharges DC-Ground Perfect protection against the worst weather conditions Designed to work without Ground Plane Stainless steel hardwares Electrical Data Type: Colinear Frequency range @ SWR = 1.5: SPO-420-5: 420-470 MHz Impedance: 50O Radiation (H-plane): 360° omnidirectional Radiation (E-plane): beamwidth @ -3 dB = 40° Radiation angle: 0° Polarization: linear vertical Gain: 3 dBd - 5.15 dBi Max. power (CW) @ 30°C: 75 Watts Grounding protection: All metal part are DC-grounded, the inner conductor shows a DC-short Connector: N-female with rubber protection cap Mechanical Data Materials: White fiberglass radome Ø 28.6mm, anodized 6063-t5 aluminium, brass, stainless steel, copper, EPDM rubber Wind load / resistance: 33 N @ 150 Km/h / 200 Km/h Wind surface: 0.027 m² Height (approx.): 780 mm Weight (approx.): 890 gr Operating temperature: -40°C to +80°C Mounting mast: Ø 35-54 mm

Posted in Fremont, CA, Electronics
